| Nguồn gốc: | Thượng Hải, Trung Quốc |
|---|---|
| Hàng hiệu: | DAESUM |
| Chứng nhận: | ISO |
| Số lượng đặt hàng tối thiểu: | 1 |
| Điện áp: | 380V, 415V | Lấp đầy độ chính xác: | ±0,2%FS |
|---|---|---|---|
| Cân nặng: | 5000 kg | Dung tích: | 200-1000bph |
| Loại container: | Lon thiếc 1-4L | Số lượng vòi phun: | 2-8 |
| Vật liệu vòi phun: | SS304/SS316/PTFE | Tốc độ đầu ra: | 7-10 lon/phút |
| hình dạng container: | Thùng thiếc vuông | Vật liệu container: | hộp kim loại |
| Cung cấp điện áp: | 415/220, 1/3phase, 50/60Hz | Chế độ lấp đầy: | Ở trên hoặc dưới mức chất lỏng với Fast & Dribble Fill |
| Hệ thống điều khiển: | Đức Siemens/Nhật Bản Omron PLC | hệ thống làm đầy: | Vòi SS304, ống thẳng SS316, phớt PTFE |
| Vật liệu bao vây: | Thép không gỉ 304 | ||
| Làm nổi bật: | 1-4L automatic tin can filling machine,electric tin can palletizing line,PLC core chemical liquid filling machine |
||
Tin Can Filling Machine with 3 Heads GZ-18ST-3(Square Metallic Tin)
*Product Application:
Applications include free flowing to viscous products, including chunky products. Fill
volumes from 5L to 25L at high flow rates with accuracies up to ±0.2% dependent upon tin
can size and type of product.
*Technical Specification:
| 1). Product | Free flow to high viscosity |
| 2). Output Speed | 7-10 Cans/Min dependent upon can size and type of product |
| 3). Container Shape | Square Tin Can |
| 4). Container Material | Metal container |
| 5). Container size | Standard 18L (More on requests) |
| 6). Voltage supply | 415/220, 1/3Phase, 50/60Hz |
| 7). Filling accuracy | Class X (0.5) (0.2%) |
| 8). Filling mode | Above or under liquid level with fast&dribble fill |
*Filling System includes:
1). Three (3) set of SS304 Nozzle equipped;
2). No spilling of the product onto clean cans and roller conveyor with hood cover under the
nozzle.
3). Quick-release, fast inter-changeable lance for easy and fast maintenance;SS316 straight
pipe;
4). Top/Low Fill, auto lowering of lance assembly together with the hood cover and retract to
its original up position;
5). METTLER TOLEDO Brand Weight Scaler with digital display;
6). Heavy duty weighting platform mounted single load cell, overload protected;
7). All parts in contact with liquid must be in SS304&PTFE seals;
8). spring assists to close filling nozzle in the even of power failure;
9). Stainless steel 304 enclosure with front viewing Perspex mounted hinge cover;
10). IP55 class control cabinet to house weighing indicator and pneumatic box to house all
pneumatic components.
*Control system includes:
1). Germany Siemens/Japan Omron PLC Control System;
2). Manual/Net/Gross Filling. Auto two stages fast/dribble fill
* Optional Item&Accessary Equipment
1). Digital Touch Screen Panel with System Integration;
2). PLC to DCS synchronization and simulation;
3). Storage tank with level controller;
4). Available to suit Hazardous Environments with Ex-proof system;
5). Tin De-palletizer and Palletizer
6). Auto Capping Machine (Both of Press-on and screw cap);
7). Check weight, labeler, robot arm palletizer,etc
8). Nozzle diving system for foamy product.
Customized according to the customer request is also allowed.
Call/email now for a quick response to your application questions.
